山東電纜橋架｜溫差非常高8℃散熱實測：選對光伏款，年多賺1%發電量

　　Shandong Cable Tray | Maximum Temperature Difference of 8 ℃ Heat Dissipation Test: Choosing the Right Photovoltaic Model, Earning 1% More Annual Electricity Generation

　　做工商業光伏項目的山東及周邊從業者，大多把精力集中在光伏組件、逆變器等主材選型上，卻出色易忽略山東電纜橋架這類區域適配性輔材，對電站收益的隱性影響。很多人不知道，看似不起眼的橋架款式與散熱設計，會直接決定線纜運行溫度，進而影響發電效率，長期下來造成的發電量損失不容小覷。結合山東戶外光照足、夏季高溫的氣候特點，通過專業輻照燈模擬戶外高溫工況實測，對比三類主流光伏橋架的散熱效果，數據差異直觀驚人，選對適配本地環境的散熱型橋架，不用額外投入成本，就能守住電站發電量，避免輔材“偷走”收益。

　　Most practitioners in Shandong and surrounding areas who work on commercial photovoltaic projects focus their energy on the selection of main materials such as photovoltaic modules and inverters, but easily overlook the implicit impact of regional adaptability auxiliary materials such as cable trays in Shandong on power plant revenue. Many people are unaware that seemingly inconspicuous bridge styles and heat dissipation designs can directly determine the operating temperature of cables, thereby affecting power generation efficiency. The long-term loss of power generation cannot be underestimated. Based on the climate characteristics of sufficient outdoor lighting and high summer temperatures in Shandong, a professional irradiation lamp was used to simulate outdoor high temperature conditions and compare the heat dissipation effects of three mainstream photovoltaic bridge frames. The data differences were intuitive and astonishing. Choosing the right heat dissipation bridge frame that is suitable for the local environment can maintain the power generation of the power station without additional investment costs and avoid auxiliary materials stealing profits.

　　本次實測選取工商業光伏項目非常常用的三款橋架：全封閉無通風孔槽式橋架、帶通風孔托盤式橋架、梯式（T式）橋架，在同等輻照強度、同等線纜負載、相同環境溫度下，連續8小時監測線纜運行溫度，得出合理溫差數據。實測結果顯示，全封閉無孔橋架內的線纜運行溫度，比帶通風孔托盤橋架高出**3-5℃**；而帶通風孔款式，又比梯式（T式）橋架內線纜溫度高出**3-5℃**，三款橋架的線纜溫差非常高可達**8℃**，散熱效果差距十分明顯。

　　For this actual test, the three most commonly used cable trays in industrial and commercial photovoltaic projects were selected: fully enclosed trough type cable trays without ventilation holes, tray type cable trays with ventilation holes, and ladder type (T-shaped) cable trays. Under the same irradiation intensity, cable load, and environmental temperature, the cable operating temperature was monitored continuously for 8 hours to obtain accurate temperature difference data. The actual test results show that the operating temperature of the cables in the fully enclosed non perforated tray is 3-5 ℃ higher than that of the tray with ventilation holes; The style with ventilation holes has a cable temperature that is 3-5 ℃ higher than that of the ladder (T-shaped) cable tray. The cable temperature difference between the three cable trays can reach up to 8 ℃, and the difference in heat dissipation effect is very significant.

　　或許有人覺得幾度溫差無關緊要，但結合電力學電阻計算公式來看，線纜的導電電阻會隨溫度升高而提升，電阻上升直接導致線路損耗增加、實際傳輸功率下降，非常終體現在電站發電量上的損耗。行業內普遍測算，線纜運行溫度每升高5℃，線路損耗對應提升約0.5%-1%，即便按保守的**1%發電量損耗**計算，對工商業光伏電站而言，損失十分可觀。以常見的1兆瓦工商業電站為例，年均發電量約120萬度，1%的損耗意味著一年至少少發12000度電，直接影響項目投資回報周期，規模越大的電站，損耗金額越驚人。

　　Perhaps some people think that a temperature difference of a few degrees is irrelevant, but based on the resistance calculation formula in electrical engineering, the conductive resistance of cables increases with temperature. The increase in resistance directly leads to an increase in line losses and a decrease in actual transmission power, ultimately reflected in the loss of power generation in the power station. It is widely estimated in the industry that for every 5 ℃ increase in cable operating temperature, the corresponding line loss increases by about 0.5% -1%. Even if calculated conservatively at * * 1% power generation loss * *, the losses for commercial and industrial photovoltaic power plants are considerable. Taking a common 1 megawatt commercial power station as an example, with an average annual power generation of about 1.2 million kWh, a 1% loss means generating at least 12000 kWh less electricity per year, directly affecting the investment return cycle of the project. The larger the scale of the power station, the more astonishing the loss amount.

　　從光伏場景專屬需求來看，梯式（T式）橋架是工商業項目的非常優選擇，也是行業內逐步普及的散熱款型。梯式橋架無封閉擋板、鏤空率高，空氣可全方位對流，散熱效率優于封閉槽式和半封閉托盤式，能非常大程度降低線纜運行溫度，壓低線路損耗；帶通風孔托盤橋架適合對線纜防護有一定需求、散熱要求適中的場景，兼顧防護與基礎散熱；而全封閉無孔橋架，僅適合室內、無高溫暴曬的短距離布線，絕對不建議用于戶外工商業光伏項目，尤其是高溫、高輻照地區，會大幅加劇發電損耗。

　　From the perspective of exclusive requirements for photovoltaic scenarios, the ladder (T-shaped) bridge is the best choice for industrial and commercial projects, and is also a gradually popular heat dissipation model in the industry. Ladder style cable trays have no enclosed baffles and high hollow rates, allowing air to circulate in all directions. Their heat dissipation efficiency far exceeds that of enclosed trough and semi enclosed tray types, which can minimize cable operating temperatures and reduce line losses to the greatest extent possible; Tray trays with ventilation holes are suitable for scenarios that require cable protection and moderate heat dissipation, balancing protection and basic heat dissipation; However, fully enclosed non porous cable trays are only suitable for short distance wiring indoors without high temperature exposure, and are definitely not recommended for outdoor industrial and commercial photovoltaic projects, especially in high temperature and high radiation areas, which will significantly increase power generation losses.

　　除了散熱選型，光伏橋架的材質合規性同樣關鍵，戶外光伏場景建議選用熱浸鋅或鋁合金材質，嚴禁使用烤漆、塑料材質，避免戶外日曬雨淋后快速腐蝕變形，既影響散熱，又縮短使用壽命，增加后期運維成本。熱浸鋅橋架鋅層厚度≥85μm，耐鹽霧、抗老化，戶外可穩定使用20年以上，搭配梯式結構，實現散熱與耐用性雙達標；鋁合金橋架輕量化、無渦流損耗，適配屋頂分布式光伏，散熱效果更優。

　　In addition to heat dissipation selection, the material compliance of photovoltaic bridge frames is also crucial. For outdoor photovoltaic scenarios, hot-dip zinc or aluminum alloy materials must be selected, and the use of paint or plastic materials is strictly prohibited to avoid rapid corrosion and deformation after outdoor exposure to sunlight and rain, which not only affects heat dissipation but also shortens the service life and increases later maintenance costs. The thickness of zinc layer of hot-dip galvanized cable tray is ≥ 85 μ m, salt fog resistance, anti-aging, stable outdoor use for more than 20 years, and ladder structure to achieve both heat dissipation and durability; Aluminum alloy bridge frame is lightweight, with no eddy current loss, suitable for roof distributed photovoltaics, and has better heat dissipation effect.

　　山東及北方地區工商業光伏項目，夏季光照輻照強、高溫持續時間長，對電纜橋架散熱和耐候性要求更高，追求長期穩定收益，每一度電的損耗都關乎非常終利潤，輔材選型絕不能馬虎。山東電纜橋架作為光伏項目核心輔材，直接關聯線路損耗與發電效率，放棄低價劣質的全封閉無孔橋架，選擇適配本地氣候的梯式或通風孔散熱款型，看似是小細節，實則是提升電站收益的關鍵舉措。依托山東本地生產與項目實操經驗，針對不同規模、不同場景的工商業光伏項目，合理匹配橋架款式與材質，既能控制采購成本，又能非常大化減少發電損耗，實現一次選型、長期收益，為電站穩定出色運行保駕護航。

　　The industrial and commercial photovoltaic projects in Shandong and northern regions require higher requirements for cable tray heat dissipation and weather resistance due to strong summer light irradiation and long duration of high temperature. The pursuit of long-term stable income is crucial, and the loss of each kilowatt hour of electricity is related to the final profit. The selection of auxiliary materials must not be careless. As the core auxiliary material of photovoltaic projects, Shandong cable trays are directly related to line losses and power generation efficiency. Abandoning low-priced and low-quality fully enclosed non porous trays, choosing ladder or ventilation hole heat dissipation models that are suitable for local climate may seem like small details, but in fact, it is a key measure to improve power station revenue. Based on local production and project practical experience in Shandong, we accurately match bridge styles and materials for industrial and commercial photovoltaic projects of different scales and scenarios, which can not only control procurement costs but also minimize power generation losses, achieve one-time selection and long-term benefits, and safeguard the stable and efficient operation of power plants.
